Stainless Steel Gear Rack Manufacturer – AISI 304 & 316L Custom Racks
Prototeque is a China-based manufacturer.
We specialize in non-standard stainless steel gear racks.
Materials: AISI 304 and AISI 316L.
Single length up to 2 meters.
Spliced solutions for 6m and 10m.
Custom stainless steel rack and pinion matching.
Factory direct. Free design review. Fast quote.
Custom AISI 316L Stainless Steel Gear Rack – Made to Drawing
This is a real production case.Made for an Italian client.Material: AISI 316L.Module: M4.Custom holes and profile.100% made to drawing
| Parameter | Specification (This Case) | Customization Options |
| Material | AISI 316L (Marine & Chemical Grade) | AISI 304 / 316L / Custom |
| Module | M4 (Module 4 stainless steel gear rack) | M3, M4, M5, Custom |
| Pressure Angle | 20° | 20° / Custom |
| Total Length | 1960.92 mm (Approx. 2m) | Single max 2m / 6m-10m Spliced |
| Cross-section | 40 x 40 mm | Custom profiles available |
| Mounting Holes | M10-6H (Depth 25mm), Ø8.5 (Depth 28mm) | M8, M10, Custom |
| Hole Pitch | 125.7 mm | Made to drawing |
| Application | Food grade & Marine/chemical | Highly corrosive environments |
Why Few Factories Make Stainless Steel Gear Racks
Most factories choose 45# steel. It is cheap, easy to machine, and can achieve high initial precision through heat treatment. But it rusts.
Stainless steel is different. Grades like AISI 304 and 316L cannot be heat-treated. They work-harden during machining, which makes high-precision grinding slow and costly. This is why AISI 316L stainless steel gear racks are rare.
But precision must last. In wet or chemical environments, a 45# steel rack will rust quickly. Rust destroys the tooth profile, and that initial precision is gone.
Prototeque makes stainless steel racks for the long run. We machine them to your drawing and manage work-hardening. We hold tight tolerances on length and hole positions. Single length up to 2 meters, with spliced solutions for 6m and 10m.
We commonly produce module 3 and module 4, but custom modules are fully supported. We also provide custom stainless steel rack and pinion matching. They are ideal for marine, chemical, and food-grade environments.
We are a factory. We handle the hard jobs. Send us your drawing, and we will quote.
Looking for a Professional Stainless Steel Gear Rack Manufacturer?
Prototeque is a China-based factory for Cremagliera inox and stainless steel gear rack. We produce AISI 304 and 316L. M3 and M4 are our common sizes, but custom modules are fully supported. We also manufacture custom Cassone – Cremagliera (rack housing) and provide rack and pinion matching.
If you are looking for a reliable Cremagliera manufacturer, or need a custom stainless steel rack and pinion for 6m/10m travel, please contact us.
Send us your drawing. We will review it for free and quote within 24 hours.
